Concept P13 · Desert modernism

Ochre Screen

Jodhpur climate context inspiration · original concept study, not a built home

Plot
30 × 60 ft
Built-up
2,520 sq ft
Floors
G+1
Bedrooms
4
Road side
front

The home: finished look

Photorealistic design concept

Ochre Screen · Exterior · daylight

Photorealistic design concept · AI-assisted concept visualisation, not a photograph of a built home. Drawings remain the dimensional reference.

Discuss this look

Exact views from the model

Rendered from the same geometry as the plans, so proportions here are true. Less styled than the concepts above.

Daylight model view · model view
Evening model view · model view
Aerial model view · model view
Front model view · model view
Native raytraced presentation · model view
Provenance and status
  • Project P13, model revision R4. Original concept study, not a completed client home.
  • Model views, floor cutaways, room views, the 3D model and drawings all come from one authored geometry.
  • Presentation studies: AI-assisted presentation study; styling reference, not a dimensionally exact model export.
  • Illustrative concept; no project-specific engineering or approval review.

Four bedrooms behind a private screened edge.

Ochre Screen is an original four-bedroom G+1 study on a 30 × 60 ft rectangular plot. The plot area is 1,800 sq ft; covered floors are 1,260 sq ft each, totalling 2,520 sq ft built-up.

Deep shadow for a hot-dry climate brief

Ochre limestone and a perforated sand-coloured lattice create privacy, deep shade and a spare planted edge. The brief also asks for a usable terrace. Jodhpur describes climate inspiration, not a completed local home. A 200 gaj enquiry only equals this plot area if the local unit means nine square feet per gaj; verify dimensions. Supplied concept sheets are not for construction.
